Furuno NavNet TZtouchXL TZT13X 13" Hybrid Control MFD

Furuno NavNet TZtouchXL TZT13X - 13" Hybrid Control MFD

Stock Availability Notice

The Furuno NavNet TZtouchXL TZT13X is the 13" version in Furuno's current flagship MFD lineup. It uses the same hybrid control system as the TZT10X - touchscreen plus RotoKey knob and physical function keys - giving you reliable control in any conditions. At 13", you get noticeably more screen real estate for split-screen views without stepping up to the all-glass TZT16X.

What's Included

• Furuno NavNet TZtouchXL TZT13X display unit
• Standard mounting hardware and bracket
• Power/data cable
• Quick start guide

Key Features

• 13" wide IPS LCD display with anti-glare glass and high brightness
• Hybrid control - touchscreen plus RotoKey knob and dedicated function keys
• Built-in 1kW TruEcho CHIRP fishfinder (CHIRP or CW mode)
• Built-in CHIRP Side-Scan (230kHz or 455kHz) - fish and structure port and starboard
• TZ Maps with BathyVision underwater terrain mapping
• AI Routing for intelligent route planning
• NMEA 0183 and NMEA 2000 connectivity
• DFF3D multibeam sonar module support
• NavPilot 300 autopilot integration
• Full networking with other TZtouchXL units
• Wireless connectivity for tablet mirroring and weather overlays

The TZT10X and TZT13X have identical sounder capability - both 1kW TruEcho CHIRP with built-in Side-Scan. The difference is screen size. At 13", the TZT13X gives you more room for split-screen layouts: running charts alongside your sonar, or sonar next to radar, without everything feeling small. If your helm has the space, most offshore fishermen find the 13" is the sweet spot in the TZtouchXL hybrid range.

Who This Suits

• Offshore fishing boats in the 5.5-8m range where the helm can take a 13" unit
• Fishermen who want hybrid control for rough weather use
• Single-display helms where you want to see charts and sonar side by side comfortably
• Dual-display setups where one screen handles navigation and one handles sonar

Furuno TZT13X FAQs

Yes. The TZT13X supports the DFF3D multibeam sonar module, which provides a 120-degree coverage swath and exceptional bottom and fish detection at depth. This is an optional extra requiring separate installation.

The TZT13X has hybrid control (touch plus physical keys). The TZT16X has a larger 16" all-glass display with touch only - no physical buttons. The TZT16X suits larger helms where you want maximum screen size. The TZT13X is better for mid-size boats or owners who prefer physical controls at sea. Note: the TZT16X is available from August 2026.
