Simrad xSonic Airmar M260 Transducer

The M260 is a 1kW, best-in-class, in-hull, depth sensor, which utilises separate 50 kHz and 200 kHz elements for excellent deep water performance and exceptional bottom and water-column detail.

Key Features

High Performance

The 1kW transducer is perfect for fast, sportfishing vessels. Track the bottom at speeds of up to 30 knots!
Deep Water Fishing

Excellent for deep water bottom and structure fishing up to 800m/2625ft.
Easy To Install

The innovative design requires no holes to be drilled in the hull and allows for bow-stern or port-starboard mounting.
Wide Operating Range

From 1 knot to 45 knots.
Dual Elements

The 200 kHz ceramic offers excellent resolution and and crisp image detail for bottom fishing. The seven-element 50 kHz array is excellent for deepr blue-water fishing. Due to the beams being narrow at both frequencies, separation of individual targets and the ability to distinguish between fish and the bottom makes finding fish easy.

Transducer Specifications

Frequency	50/200 kHz
Power Rating	1kW
Speed Sensor	No
Temperature Sensor	No
Mounting Style	In-Hull (Tank mouted)
Elements	8
Beamwidth @ -3dB	19 (50 kHz) 6 (200 kHz)
