Fusion® MS-RA60K1SPG Marine Stereo Kit

Magnify the moment with the Fusion® MS-RA60 marine stereo & EL Non illuminated (Grey) speakers. This kit places the perfect soundtrack at your fingertips with whatever you need to create a remarkable music experience in your vessel at a superior value. The stereo feature contemporary looks, Multi-Zone ™ technology in 2 zones and a built-in Class-D amplifier for greater efficiency and greater output. Advanced connectivity options offer you the ability to control the stereo from your smart device or Garmin watch.

• Kit consist of stereo, two speakers and accessories
• Conveniently update software program by means of BLUETOOTH® from the Fusion-Link™ app on your suitable smart device
• Stereo features Multi-Zone ™ modern technology in two areas as well as a Class-D amplifier for higher performance and greater output
• Control your music from your compatible smartphone or Garmin watch
• Fusion® audio speakers use clear audio reproduction
• Kits pair with extra Fusion® speakers, amplifiers, subwoofers and accessories (sold separately) to produce an enhanced audio experience

IPX6 AND IPX7 INGRESS PROTECTION

Designed and engineered for the harsh marine environment, the Fusion stereos have an IPX6 and IPX7-rated water-resistant front panel to perform and last on board.

MODERN DESIGN AND AESTHETICS

Providing uniformity across the helm, the black front face blends seamlessly into black glass panels, complementing other electronics and MFDs for a tidy and elegant installation.

DESIGNED AND ENGINEERED FOR THE MARINE ENVIRONMENT

The Fusion speakers have an IP65 rating for protection against dust and water ingress and have been tested to a high level of protection against salt fog and UV.

MODERN DESIGN AND AESTHETICS

Tested to international standards for pressure and water ingress, the Fusion speakers are designed and built for superior quality and robustness.

QUALITY MATERIALS AND ACOUSTIC ENGINEERING

The Fusion speakers incorporate high-quality materials and marine-specific design elements, ensuring they look and sound great on the water.

Stereo Specifications
Physical dimensions (HxWxD)	MS-RA60: 2.68″ x 6.18″ x 4.06″ (68 x 156.9 x 103.2 mm)
Weight	MS-RA60: 11.1 oz (316 g)
Water rating	IPX6 and IPX7 (front panel only, when properly installed)
Power input	10.8-16 VDC
Operating temperature range	32° to 122° F (0° to 50° C)
Current (max.)	15 A
Bluetooth® wireless range	Up to 30 ft (10 metres)
ANT wireless range	Up to 10 ft (3 metres)
Wireless frequencies/protocols	Bluetooth 2.4 GHz @ +12 dBm nominal
Compass-safe distance	5.9″ (150 mm)
Display	MS-RA60: 2.3″ perimeter bonded monochrome dot matrix LCD
Built-in amplifier	Class-D (minimum 4 Ohm impedance)
Peak power	MS-RA60: 180 W
Rated power output (4 Ohm)	MS-RA60: 22 W rms x 4 @ 14.4 V input < 10% THD
Fusion-Link™ control	MS-RA60: Yes (with smartphone and Garmin watch)
Multi-Zone™ technology	2 zones
Bluetooth wireless technology	Yes
ANT wireless technology	Yes
DAB+ ready	MS-RA60: Yes (DAB tuner built in)
Multi-language interface	MS-RA60: Dutch, English, French, German, Italian, Spanish
Software updates	MS-RA60: Over-the-air software updates via Bluetooth wireless technology using the Fusion-Link app
Warranty	1 year
Sources	MS-RA60: AM/FM/Bluetooth/AUX x1/DAB+ (available in Europe and Australia only)
Auxiliary input	One RCA input (AUX)
AM/FM radio	One Motorola antenna connector port
Speaker	MS-RA60: 4 x speaker connections (2 zone amplified)
RCA Pre-out (left, right and subwoofer)	MS-RA60: 1 zone (requires external amplification)
Line out	MS-RA60: Zone 1 (L + R, requires external amplification)
Subwoofer out	MS-RA60: Zone 1 (requires external amplification
Speaker Specifications
Physical dimensions (HxWxD)	EL Speaker: 6.93″ x 2.32″ (176 x 59 mm)
Water rating	IP65
Configuration	EL Speaker: Full range
Speaker size	6.5″
Peak power (Watts)	EL Speaker: 80 W
RMS power (Watts)	EL Speaker: 20 W
Sensitivity (1 watt/1 metre)	EL Speaker: 88 dB
Frequency response	EL Speaker: 45 Hz-16 kHz
Nominal impedance	4 ohm
Recommended amplifier power (RMS)	EL Speaker: 20-40 W/Ch
Operating temperature range	32° to 122° F (0° to 50° C)
Voice coil diameter	EL Speaker: 0.79″
Cone material	Polypropylene cone with cloth surround
Compass-safe distance	EL Speaker: 100″ (254 cm)
Warranty	EL Speaker: 1 year
Mounting diameter clearance	EL Speaker: 5.12″ (130 mm)
Mounting depth clearance	EL Speaker: 1.69″ (43 mm)
